VB ARMOR

Step up to the next level in safety, strength, and performance. VB Armor is stronger than 30-pound felt, but it’s lighter and easier to handle, making your job easier.

VB ARMOR
Back to Products
Brochure
Download

Step up to the next level in safety, strength, and performance. VB Armor is stronger than 30-pound felt, but it’s lighter and easier to handle, making your job easier. VB Armor includes all the features of VB Shield, from the cutting-edge SlipGuard walking surface to five times more coverage per roll than Type 30 felt.

Like VB Shield, it meets building codes for residential and commercial projects, it is completely inorganic and asphalt-free (meaning no rotting or molding), and it is treated to resist excessive degradation from normal UV exposure for up to six months. So when you need the next level in roofing underlayment, VB Armor delivers premium quality you can count on.

TYPICAL PHYSICAL PROPERTIES

PROPERTY ASTM Min. Average roll value Tolerance
Color Grey-White
Roll Width (in.) 48″ -0/+1/4”
Roll Length (ft.) 250
Total fabric weight (gsm) 155.50 +/- 5
Scrim (Weave Count) 9.5X10.5
MD Grab Strength ASTM D751 165 LBS 160 LBS MIN
CD Grab Strength ASTM D751 170 LBS 155 LBS MIN.
MD Trapezoidal Tear ASTM D2261 33 LBS 30 LBS MIN.
CD Trapezoidal Tear ASTMD 2261 31 LBS 30 LBS MIN
Elongation (MD/CD) % ASTM D751 19/18 15 MIN
Sandwich coating (gsm) 20
Antislip coating (gsm) 24
C O F ASTMD1894 0.46 0.3 MIN

ROLL SIZES

48” X 250’ (1.22m X 76.20m)

CODE AND STANDARD COMPLIANCE

  • ATSM D 226, Type II
  • Standard Specification for Asphalt Saturated Organic Felt
  • Used in roofing and waterproofing
  • ICC-ES AC 207
  • Acceptance Criteria for Polypropylene Underlayments
  • CSA A 123.3
  • Acceptance Saturated Organic Roofing Felt
  • ASTM E 108/UL 790 – Class A
  • Standard Test Methods for Fire Tests of Roof Coverings
  • CSA 220.1

APPLICATIONS

Performance-grade synthetic roofing underlayment for use under:

  • Asphalt glass fiber mat shingle
  • Organic felt shingle
  • Metal (standing seam)
  • Tile
  • Slate
  • Approved for both vented and non-vented roof applications

WARRANTY

A 50-year limited warranty applies to All VB Synthetic underlayments. Please contact VB Synthetics or visit vbsynthetic.com for details. No warranty, express or implied, is given as to the merchantability and fitness for a particular purpose, or otherwise for applications outside the scope of the installation guidelines.
